Smart Linear Air Grille

Etched Universal Aluminum Air Grille for Access Floor Panels Plenum Air  The Universal Aluminum ASM 6 inch by 18 inch Smart Linear Air Grille allows conditioned air in the plenum space in data centers raised floor tiles. Universal Air Grille Standard Features Standard 818 air grille requires a 6″x18″ cutout in floor panel. (Other sizes are available) Grille is made entirely of aluminum with top surface extruded bars at 1/4″ apart to be “pencil proof”. Exposed surface of grille is etched 6061-T6 aluminum. Etched and anodized with feathered flange to avoid a tripping hazard. Compatible with both carpeted or any laminate raised access floor panels. Air Grille Options Optional damper assembly has opposed blades and can be adjusted from the top with a standard screwdriver. Optional electrical insulation band allows grille to be insulated from steel floor panel Other sizes are available Please note this product has a 12 week lead time.  CS-7250Air Grille Smart-Grille Aluminum Specifications Request a Quote
